| FLUTE DIAMETER | SHANK DIAMETER | OVERALL LENGTH | FLUTE LENGTH | FLUTE DIAMETER | SHANK DIAMETER | OVERALL LENGTH | FLUTE LENGTH |
|---|---|---|---|---|---|---|---|
| 4.00 | 3.50 | 56 | 20 | 12.00 | 10.00 | 80 | 28 |
| 4.50 | 4.00 | 63 | 22 | 12.50 | 10.00 | 80 | 28 |
| 5.00 | 4.00 | 63 | 22 | 13.00 | 10.00 | 80 | 28 |
| 5.50 | 5.00 | 63 | 22 | 13.50 | 12.50 | 90 | 32 |
| 6.00 | 5.00 | 63 | 22 | 14.00 | 12.50 | 90 | 32 |
| 6.50 | 5.00 | 63 | 22 | 14.50 | 12.50 | 80 | 32 |
| 7.00 | 6.00 | 71 | 25 | 15.00 | 12.50 | 90 | 32 |
| 7.50 | 6.00 | 71 | 25 | 15.50 | 12.50 | 90 | 32 |
| 8.00 | 6.00 | 71 | 25 | 16.00 | 12.50 | 90 | 32 |
| 8.50 | 8.00 | 71 | 25 | 16.50 | 12.50 | 90 | 32 |
| 9.00 | 8.00 | 71 | 25 | 17.00 | 16.00 | 90 | 32 |
| 9.50 | 8.00 | 71 | 25 | 17.50 | 16.00 | 100 | 36 |
| 10.00 | 8.00 | 71 | 25 | 18.00 | 16.00 | 100 | 36 |
| 10.50 | 10.00 | 80 | 28 | 18.50 | 16.00 | 100 | 36 |
| 11.00 | 10.00 | 80 | 28 | 19.00 | 16.00 | 100 | 36 |
| 11.50 | 10.00 | 80 | 28 | 19.50 | 16.00 | 100 | 36 |
| Item | ALTIN | TIALN | TISIN | NANO |
|---|---|---|---|---|
| Hardness | 3200 | 2800 | 3600 | 42(GPA) |
| Thickness | 2.5-3 | 2.5-3 | 3 | 3 |
| Oxidation temp | 900 | 800 | 1000 | 1200 |
| Friction coefficient | 0.3 | 0.3 | 0.45 | 0.4 |
| Color | Black | Violet | Copper | Blue |
| Machine | Country | Application |
|---|---|---|
| Michael deckel | Germany | Big diameter milling cutter |
| ANCA | Australia | Small diameter milling cutter |
| TTB | Switzerland | Micro diameter milling cutter |
| WALTER | Germany | Non standard size cutter |
Quality has never been more important than today. We continually invest in the latest technology and equipment in keeping with our pledge for quality excellence. Only the best micro grain carbide available is used in building our tools. We offer a full line of tools, as well as custom manufactured tools in Solid Carbide/HSS Cobalt 8%, End Mills, Reamers, Step Drills and Form Tools are just a few of the types of tools that we will custom manufacture and coat to your specifications. We work together with you to make the exact cutting tool you are looking for.
